Migration

ENSv2 provides a migration framework for transitioning ENSv1 .eth names to the new system. Migration is a two-phase process: premigration reserves all existing names in v2 automatically, then migration lets owners claim their names by transferring their v1 tokens to a migration controller.

Overview

ENSv1 Token Types

Migration supports all .eth descendants. The migration path depends on the token type:

Key Definitions

• RESERVED: a v2 registry slot with an expiry and resolver but no owner. Created during premigration.
• REGISTERED: a v2 registry slot with an owner. Created when a user migrates their v1 token.
• Graveyard: the burn address for migrated v1 tokens. Also cleans up stale v1 registry entries.

Time Constants

Premigration

Before users can migrate, every unexpired v1 name is batch-reserved in the v2 ETH Registry by the BatchRegistrar. This happens automatically and does not require any user action.

For each name:

• Status: set to RESERVED
• Expiry: expiryV1 + BONUS_PERIOD
• Resolver: set to ENSV1Resolver, which performs wildcard fallback to the v1 ENS registry
• Owner: not set (RESERVED names have no owner)

After premigration, new v1 .eth registrations are disabled. Names continue to resolve through v1 during this phase because ENSV1Resolver mirrors v1 resolution.

Migration Paths

Migration is initiated by the name owner transferring their v1 token to the appropriate controller. The controller promotes the pre-existing RESERVED slot to REGISTERED, setting the owner, resolver, subregistry, and role bitmap. The v1 token is forwarded to the Graveyard.

The v2 owner specified during migration does not need to match the v1 owner. This allows migrating directly to a new wallet or smart account.

Unwrapped Names

Unwrapped 2LD names (BaseRegistrar ERC-721 tokens) are migrated via the UnlockedMigrationController.

1. Transfer the ERC-721 token via safeTransferFrom with an encoded data payload specifying: label, new owner, resolver, and subregistry
2. The controller reclaims the token on the BaseRegistrar and clears the v1 resolver
3. The token is sent to the Graveyard
4. The name is promoted from RESERVED to REGISTERED in the v2 ETH Registry with the provided parameters
5. The token is granted the same roles as a fresh ETHRegistrar.register() (REGISTRATION_ROLE_BITMAP)

Unlocked Wrapped Names

Unlocked 2LD names (NameWrapper ERC-1155 tokens without CANNOT_UNWRAP) are also migrated via the UnlockedMigrationController.

1. Transfer the ERC-1155 token via safeTransferFrom (or batch via safeBatchTransferFrom) with an encoded data payload
2. The controller verifies the name is NOT locked (reverts NameIsLocked otherwise)
3. The token is unwrapped to the Graveyard and the v1 resolver is cleared
4. The name is promoted from RESERVED to REGISTERED with the provided parameters
5. Token roles are the same as ETHRegistrar.register()

Locked Names

Locked names (NameWrapper ERC-1155 tokens with CANNOT_UNWRAP) have irrevocable restrictions that must be preserved. The migration path depends on the name level:

• 2LD: transfer to LockedMigrationController
• 3LD+: transfer to the parent name's WrapperRegistry (the parent must have migrated first)

The migration flow:

1. Transfer the ERC-1155 token to the appropriate receiver
2. The controller verifies the token is emancipated (locked or detached)
3. If getApproved() is non-null after transfer, migration reverts (FrozenTokenApproval). Note: if CANNOT_APPROVE is not set, approval is automatically cleared during transfer, so this only triggers for tokens with CANNOT_APPROVE burned and an existing approval.
4. ENSv1 fuses are converted to ENSv2 roles (see Fuse-to-Role Conversion)
5. A WrapperRegistry is always deployed as the subregistry, replicating the v1 fuse-based access control using v2's EAC system
6. The resolver is cleared, unless CANNOT_SET_RESOLVER is burned, in which case the existing v1 resolver is preserved. If the preserved resolver is a known PublicResolver, it is replaced with PublicResolverV2
7. The token is not unwrapped and stays in the receiver until expiry (the LockedMigrationController for 2LD, or the parent's WrapperRegistry for 3LD+)
8. The name is promoted from RESERVED to REGISTERED (for 2LD) or registered directly (for 3LD+) with the converted roles

Detached Names

Detached names are emancipated children of locked parents that don't have CANNOT_UNWRAP set (3LD+ only). They are migrated via the parent's WrapperRegistry.

1. Transfer the ERC-1155 token to the parent's WrapperRegistry
2. The token is unwrapped to the Graveyard and the resolver is cleared
3. The name is registered with the same token roles as ETHRegistrar.register()

Fuse-to-Role Conversion

When migrating locked names, ENSv1 fuses are converted to ENSv2 roles. The key principle: a burned fuse that restricts an action means the corresponding role is not granted.

Admin roles (the << 128 shifted counterparts) are only granted when CANNOT_BURN_FUSES is not set. If fuses are frozen, only regular roles are granted, preventing any further permission changes in v2.

Token Roles

Subregistry Roles

These roles are granted to the name owner on the WrapperRegistry's ROOT_RESOURCE, giving them contract-wide authority over the subregistry.

Graveyard

The Graveyard contract is the burn address for migrated v1 tokens. It receives ERC-721 tokens (from unwrapped migration) and ERC-1155 tokens (from unlocked/detached migration) and holds them until expiry.

Beyond holding tokens, the Graveyard can actively clean up the v1 registry:

// Anyone can call this to clean up v1 registry entries for migrated names
Graveyard.clear(names)

The clear() function recursively walks the v1 namespace hierarchy for each name, clearing resolvers and subnode records. This prevents stale v1 resolution for names that have been migrated to v2. It handles:

• Owned names: clears resolver and subnode records
• Locked names (still in NameWrapper): validates ownership by the Graveyard
• Expired names: reclaims via the v1 BaseRegistrar, then clears

ENSv1 Continuity

Not all names will migrate immediately. ENSv2 provides mechanisms to keep unmigrated names functional.

ETHRenewerV1

The ETHRenewerV1 contract renews RESERVED (premigrated but not yet migrated) names using v2 pricing logic, and syncs the expiry back to the v1 BaseRegistrar:

// Renew a RESERVED name (syncs v1 expiry automatically)
ETHRenewerV1.renew(label, duration, paymentToken, referrer)

// Batch-sync NameWrapper expiry with BaseRegistrar
ETHRenewerV1.syncWrapper(labels)

• A RESERVED v2 name is always in sync with its v1 Registered or Grace state
• The v2 ETHRegistrar cannot register RESERVED names (it lacks ROLE_REGISTER_RESERVED), so unmigrated names are protected until they expire
• ENSV1Resolver continues resolving unmigrated names until the v2 reservation expires

Unmigratable Names

Some names are structurally unable to migrate (see Restrictions). These names remain fully functional on v1:

• Resolution continues via ENSV1Resolver as long as the v2 reservation is active
• Renewals work via ETHRenewerV1, keeping the v1 and v2 expiries in sync
• v1 fuses, resolver, and ownership remain unchanged

The only v2 features unavailable to unmigratable names are per-record permissions, aliasing, and the new resolver. Once the name expires in both v1 and v2, the Graveyard can clear its v1 namespace and the name becomes available for fresh registration in v2.

What Happens to Unmigrated Names

Names that could migrate but don't will eventually expire. Their v1 tokens expire, leaving the v1 registry state frozen (resolver, owner, fuses all unchanged). The v2 RESERVED slot also expires. Once both have expired, the name becomes available for fresh registration in v2 via the ETHRegistrar.

Scenarios

100 days remaining

A name with 100 days left in v1 is premigrated.

The RESERVED slot has 162 days left (100 + 62 day bonus). ENSv1 expires after 100 days and becomes available after 190 days (100 + 90 day grace). ENSv2 expires after 162 days and becomes available after 190 days (162 + 28 day grace). Both systems make the name available at the same time.

Migrates then renews

A name with 50 days remaining is premigrated, migrated, then renewed for 50 days.

The RESERVED slot has 112 days (50 + 62). The owner migrates, promoting to REGISTERED. The v1 token goes to the Graveyard with 50 days left. The owner renews via ETHRegistrar for 50 days, extending the v2 registration to 162 days. ENSv1 becomes available after 140 days (50 + 90), ENSv2 after 190 days (162 + 28).

In grace period, renews out of grace

A name has 29 days left in the v1 grace period (i.e., -61 days remaining).

The RESERVED slot has 1 day left (-61 + 62). The owner uses ETHRenewerV1 to renew for 62 days. ENSv1 expires after 1 day (-61 + 62) and becomes available after 91 days. ENSv2 expires after 63 days (-61 + 62 + 62) and becomes available after 91 days. The token can now be transferred and migrated.

NameWrapper expiry out of sync

The NameWrapper shows an expired name but the BaseRegistrar still has it as registered.

Use ETHRenewerV1.syncWrapper(labels) to batch-sync the NameWrapper expiry with the BaseRegistrar expiry.

What Users Need to Do

.eth Name Owners

Premigration happens automatically. To migrate your name to v2:

1. Transfer your v1 token to the appropriate migration controller:
   • Unwrapped or unlocked: UnlockedMigrationController
   • Locked: LockedMigrationController
2. Specify the new v2 owner, resolver, and subregistry in the transfer data
3. The v2 owner can be a different address than the v1 owner (e.g., migrating to a smart account)

If your name is in the v1 grace period, use ETHRenewerV1 to renew it first.

Subname Owners

If you own a locked subname (3LD+), your parent must migrate first. Once the parent has migrated, transfer your token to the parent's WrapperRegistry.

Unlocked 3LD+ subnames cannot be migrated through the migration controllers. They must be registered directly in v2 once their parent has a v2 registry.

What Happens to Records

• Locked names with CANNOT_SET_RESOLVER: the v1 resolver is preserved. If it's a known PublicResolver, it's replaced with PublicResolverV2 (records may need to be copied separately).
• All other names: the v1 resolver is cleared during migration. Set up a new resolver in v2.

Restrictions

Migration is not possible in the following cases:

• The v1 token is not transferable (owner or approval restrictions)
• Locked names with CANNOT_TRANSFER burned
• Locked names with CANNOT_APPROVE burned and a non-null getApproved() (reverts FrozenTokenApproval)
• 3LD+ subnames whose parent has not migrated yet

Contracts
